带通滤波器

封装

产品型号

尺寸(LxWxT)mm

频率(MHz)

插入损耗(dB/max)

备注

·0907

BF0907-W2R4PBA

0.9*0.7*0.65

2400 - 2500

0.9

1005

BF1005-A2R4DAE

1.0*0.5*0.38

2400 - 2500

3.8

BF1005-E5R4DAP

1.0*0.5*0.45

2490 - 5950

1

BF1005-K1R8DAB

1.0*0.5*0.38

1710 - 1910

2

BF1005-K2R4DAA

1.0*0.5*0.38

2400 - 2500

2.5

BF1005-K2R4DAD

1.0*0.5*0.4

2400 - 2500

3

BF1005-L2R4DAB

1.0*0.5*0.38

2400 - 2500

2

BF1005-L2R4DAG

1.0*0.5*0.38

2400 - 2500

2

1109

BF1109-A2R4NCC

1.1*0.9*0.45

2400 - 2500

1.2

BF1109-L2R4NCA

1.1*0.9*0.6

2400 - 2500

1 ; 1.2 ; 1.3

1411

BF1411-L2R4NCA

1.4*1.1*0.6

2400 - 2500

1 ; 1.2

BF1411-K2R4NCA

1.4*1.1*0.8

2400 - 2500

1.8

1608

BF1608-A7R2NAA

1.6*0.8*0.7

6240 - 8240

2.5

BF1608-E2R4DAA

1.6*0.8*0.6

2400 - 2500

3

BF1608-E2R4DRA

1.6*0.8*0.6

2400 - 2500

3

BF1608-E5R5DAB

1.6*0.8*0.5

5150 - 5900

4 ; 2.5

BF1608-E5R5TAA

1.6*0.8*0.6

4900 - 5150

1.7 ; 1.5

5150 - 5850

BF1608-K2R4DAA

1.6*0.8*0.6

2400 - 2500

2

BF1608-K2R4NAA

1.6*0.8*0.6

2400 - 2500

3

BF1608-H5R5DAB

1.6*0.8*0.6

4900 - 5850

1.5

BF1608-K2R4NAK

1.6*0.8*0.6

2400 - 2500

2.5

BF1608-L1R9NDB

1.6*0.8*0.7

1880 - 2025

1.9

BF1608-L1R9NDC

1.6*0.8*0.7

1805 - 2025

2

BF1608-L2R4DAA

1.6*0.8*0.6

2400 - 2500

1.7

BF1608-L2R4DAB

1.6*0.8*0.6

2400 - 2500

2.5

BF1608-L2R4DAD

1.6*0.8*0.6

2400 - 2500

3.2

BF1608-L2R4DAK

1.6*0.8*0.6

2400 - 2500

2

BF1608-L2R4DAS

1.6*0.8*0.6

2400 - 2500

2.5

BF1608-L2R4NAF

1.6*0.8*0.6

2400 - 2500

1.4

BF1608-L2R4DCA

1.6*0.8*0.5

2400 - 2500

2.2

BF1608-L2R4NAD

1.6*0.8*0.6

2400 - 2500

3.2

BF1608-L2R4NAE

1.6*0.8*0.6

2400 - 2500

2

BF1608-L2R4NAG

1.6*0.8*0.6

2400 - 2500

2.7

BF1608-L2R4NAM

1.6*0.8*0.6

2400 - 2500

2.5

BF1608-L2R6DAC

1.6*0.8*0.55

2500 - 2700

2.2

BF1608-L3R6DAC

1.6*0.8*0.55

3300 - 3700

1.8

BF1608-L5R5DAB

1.6*0.8*0.6

4900 - 5850

2

BF1608-L5R5NAB

1.6*0.8*0.6

4900 - 5850

1.5 ; 1.7

BF1608-N2R4DAC

1.6*0.8*0.4

2400 - 2500

2.4 ; 2.8

BF1608-N2R4NRB

1.6*0.8*0.45

2400 - 2500

3

BF1608-N5R4NAG

1.6*0.8*0.6

4900 - 5950

1

BF1608-N5R4NAM

1.6*0.8*0.6

4900-5150

1.2

5150-5950

1

BF1608-N5R5DAB

1.6*0.8*0.5

5150 - 5850

4.5 ; 3

BF1608-R5R5NAB

1.6*0.8*0.6

5150 - 5950

0.6 ; 0.8

BF1608-N5R5NAH

1.6*0.8*0.6

5150 - 5950

0.7

BF1608-N5R5NAN

1.6*0.8*0.59

5150 - 5950

0.8

BF1608-R6R1NAC

1.6*0.8*0.65

5170 - 7125

0.9

2012

BF2012-B5R5BAA

2.0*1.25*0.95

5150 - 5825

1.8

BF2012-B5R5BAB

2.0*1.25*0.95

5150 - 5875

2.8

BF2012-B5R5BAC

2.0*1.25*0.95

5150 - 5825

1.8

BF2012-B5R5DAA

2.0*1.25*0.95

5150 - 5875

1.5

BF2012-B5R5DAB

2.0*1.25*0.95

5150 - 5875

2.5

BF2012-B5R5DAC

2.0*1.25*0.95

5150 - 5875

1.5

BF2012-B5R5DAD

2.0*1.25*0.95

4900 - 5875

2

BF2012-E2R4DAA

2.0*1.25*0.55

2400 - 2500

2.8

BF2012-E4R0GAA

2.0*1.25*0.7

3100 - 4900

2

BF2012-E4R2DAA

2.0*1.25*0.95

2400 - 5900

2

BF2012-E5R5DAB

2.0*1.25*0.95

5150 - 5875

1.8

BF2012-E5R5DAC

2.0*1.25*0.95

4900 - 5920

1.5

BF2012-E5R5DAD

2.0*1.25*0.95

4900 - 5875

1.8

BF2012-F2R4DAA

2.0*1.25*0.95

2400 - 2500

2.2

BF2012-H5R5DAA

2.0*1.25*0.95

5150 - 5750

5

BF2012-L2R4DAA

2.0*1.25*0.55

2400 - 2500

1.5

BF2012-L2R4DAC

2.0*1.25*0.55

2400 - 2500

1.6

BF2012-L2R4DAD

2.0*1.25*0.7

2400 - 2500

2.9

BF2012-L2R4DAG

2.0*1.25*0.95

2400 - 2500

1.3

BF2012-L2R4DAM

2.0*1.25*0.95

2400 - 2500

1.6

BF2012-L2R4DAR

2.0*1.25*0.95

2400 - 2500

1.2

BF2012-L2R4FCA

2.0*1.25*0.7

2400 - 2500

1.7

BF2012-L2R4KCA

2.0*1.25*0.55

2400 - 2500

2.6

BF2012-L2R4KCB

2.0*1.25*0.55

2400 - 2500

2.5

BF2012-L2R4KCC

2.0*1.25*0.55

2400 - 2500

2

BF2012-L2R4KCD

2.0*1.25*0.55

2400 - 2500

2.7

BF2012-L2R4NAA

2.0*1.25*0.9

2400 - 2500

1.2

BF2012-L2R4NAB

2.0*1.25*0.45

2400 - 2500

2.5

BF2012-L2R4NAC

2.0*1.25*0.45

2400 - 2500

2.5

BF2012-L2R4NAR

2.0*1.25*0.9

2400 - 2500

0.9

BF2012-L2R4NBA

2.0*1.25*0.7

2400 - 2500

1.8

BF2012-L2R4NCA

2.0*1.25*1.0

2400 - 2500

1.1

BF2012-L2R4NDA

2.0*1.25*0.8

2400 - 2500

2

BF2012-L2R5DAA

2.0*1.25*0.95

2300 - 2690

2

BF2012-L3R6DAA

2.0*1.25*0.95

3300 - 3900

1.8

BF2012-L5R5DAA

2.0*1.25*0.55

4900 - 5850

2.2

BF2012-L5R5DAB

2.0*1.25*0.95

5150 - 5900

2.8

BF2012-L5R5DAC

2.0*1.25*0.95

5150 - 5900

3.5

BF2012-L5R5KCB

2.0*1.25*0.7

4900 - 5825

5 ; 1.8

BF2012-L5R5DBC

2.0*1.25*0.95

4900 - 5950

2

BF2012-L5R5DBC

2.0*1.25*0.95

4900 - 5950

2

BF2012-N1R6DAA

2.0*1.25*0.95

950 - 2200

3

BF2012-N2R4DAA

2.0*1.25*0.95

2400 - 2500

1.5

BF2012-N2R4DAC

2.0*1.25*0.95

2400 - 2500

1.9

BF2012-N2R4NCA

2.0*1.25*1.0

2400 - 2500

1.3

BF2012-N5R5DAC

2.0*1.25*0.95

5150 - 5850

3.5

BF2012-N5R5DAE

2.0*1.25*0.55

4900 - 5000

2 ; 2.3

5000 - 5950

1.8 ;2.1

BF2012-N2R4NLA

2.0*1.25*0.55

2400 - 2500

2

BF2012-W2R4DAA

2.0*1.25*0.95

2400 - 2500

2.2

2520

BF2520-B2R4CAA

2.5*2.0*0.9

2400 - 2500

1.8

BF2520-B2R4CAB

2.5*2.0*0.9

2400 - 2500

2.5

BF2520-B2R4CAC

2.5*2.0*0.9

2400 - 2500

1.5

BF2520-B2R4CAD

2.5*2.0*0.9

2400 - 2500

2.2

BF2520-E2R3CAC

2.5*2.0*0.9

2300 - 2500

2

BF2520-E2R4CAB

2.5*2.0*0.9

2400 - 2500

2.5

BF2520-E2R4CAC

2.5*2.0*0.9

2400 - 2500

1.5

BF2520-E2R4CAE

2.5*2.0*0.9

2400 - 2500

2.5

BF2520-E2R4CAF

2.5*2.0*0.9

2400 - 2500

3

BF2520-E2R4CAG

2.5*2.0*0.9

2300 - 2500

3.2

BF2520-E2R4CBB

2.5*2.0*0.6

2400 - 2500

2.5

BF2520-E2R6CAG

2.5*2.0*0.9

2495- 2700

3

BF2520-E3R9CAA

2.5*2.0*0.9

3168 - 4752

2.5

BF2520-E5R5CAE

2.5*2.0*0.95

4900 - 5900

4.5

BF2520-E5R4CAA

2.5*2.0*1.0

4900 - 5850

1.2

BF2520-E5R5CAF

2.5*2.0*0.95

4940 - 5850

3.5；3.0

5150 - 5825

BF2520-K1R9CAA

2.5*2.0*1.1

1893 - 1920

2.8

BF2520-K2R4CAE

2.5*2.0*1.1

2400 - 2500

2.6

BF2520-L2R4CAA

2.5*2.0*0.95

2400 - 2500

2.8

BF2520-L2R4CAB

2.5*2.0*0.9

2400 - 2500

1.5

BF2520-L2R4CAC

2.5*2.0*0.95

2400 - 2500

1.2

BF2520-L2R4CAD

2.5*2.0*0.95

2400 - 2500

1.2

BF2520-L2R4CAE

2.5*2.0*0.95

2400 - 2500

2.4

BF2520-L2R4CAF

2.5*2.0*0.95

2400 - 2500

3.5

BF2520-L3R4CAA

2.5*2.0*0.95

3300 - 3560

3

BF2520-L3R7CAA

2.5*2.0*0.95

3540 - 3800

3

BF2520-N1R9CAA

2.5*2.0*1.1

1893 - 1920

1.8

BF2520-L3R4CAB

2.5*2.0*0.95

3100 - 3600

2

BF2520-N2R1CAA

2.5*2.0*0.9

2100 - 2200

3.2

3216

BF3216-A2R4DAA

3.2*1.6*0.95

2400 - 2500

2.5

BF3216-A5R8DAA

3.2*1.6*0.95

5750 - 5850

2

BF3216-B2R4AAA

3.2*1.6*0.95

2400 - 2500

2

BF3216-B2R4BAA

3.2*1.6*0.95

2400 - 2500

2.5

BF3216-B2R4DAA

3.2*1.6*0.9

2400 - 2500

2.5

BF3216-B2R4DAB

3.2*1.6*1.3

2400 - 2500

2

BF3216-E1R4DAA

3.2*1.6*1.3

950 - 1850

3.5

BF3216-E1R6DAA

3.2*1.6*1.3

1257 - 1850

3

BF3216-E2R4BAA

3.2*1.6*0.95

2400 - 2500

2.5

BF3216-E5R1FAA

3.2*1.6*0.95

3100 - 7160

1.6

BF3216-L1R9DAB

3.2*1.6*1.3

1893 - 1920

3

BF3216-L1R9DAC

3.2*1.6*1.3

1880 - 1930

1.65

BF1608-R6R1NAA

3.2*1.6*0.65

5150 - 5710

1

5710 - 5925

0.9

5925 - 6425

1.1

6425 - 7125

1.8

3225

BF3225-A5R5CAB

3.2*2.5*1.5

5150 - 5500

2.5；1.5

5500 - 5900

BF3225-B2R4CAA

3.2*2.5*1.5

2400 - 2500

2.5

BF3225-B2R4CAC

3.2*2.5*1.5

2400 - 2500

2.3

BF3225-B2R4CAD

3.2*2.5*1.5

2400 - 2500

1.3

BF3225-E2R4CAE

3.2*2.5*1.5

2400 - 2500

2.5

BF3225-E5R5CAB

3.2*2.5*1.5

5150 - 5500

2.5；1.5

5500 - 5900

BF3225-NR20FAA

3.2*2.5*1.5

174 - 237

1.5

BF3225-L1R4NAA

3.2*2.5*2.0

1125 - 1675

1.8

4532

BF4532-A2R0NAA

4.5*3.2*1.5

950 - 3000

2.5

BF4532-E2R0CAA

4.5*3.2*1.5

1500 - 2500

2.5

BF4532-F2R5CAA

4.5*3.2*1.5

2500 - 2686

2

BF4532-L1R2CAC

4.5*3.2*1.5

950 - 1525

2.8

BF4532-L1R2CAD

4.5*3.2*1.5

950 - 1525

2.8

BF4532-R5R4CAE

4.5*3.2*2.2

5170 - 5700

2.3

5700 - 5725

2.5

BF4532-R5R5CAA

4.5*3.2*2.0

5150 - 5815

2.8

5815 - 5825

3

5825 - 5835

3.1

5835 - 5850

3.3

BF4532-R6R2CAE

4.5*3.2*2.2

5935 - 6425

2.5

BF4532-R6R6CAA

4.5*3.2*2.2

6100 -7125

2.8

8629

BF8629-5R2-180

8.56*2.9*3.86

5150 - 5320

2.4

5320 - 5330

2.5

BF8629-5R7-360

8.56*2.9*3.25

5490 - 5850

2.5
