可控硅

可控硅(Silicon Controlled Rectifier) 简称SCR，是一种大功率电器元件，也称晶闸管。它具有体积小、效率高、寿命长等优点。在自动控制系统中，可作为大功率驱动器件，实现用小功率控件控制大功率设备。它在交直流电机调速系统、调功系统及随动系统中得到了广泛的应用。

在线咨询

全国热线

0755-23761301

芯片参数 / PRODUCT PARAMETERS

Part Number	VDRM	VRRM	IT(RMS)	VGT	IGT	IGT	IGT@VAK	Package
Part Number	(V)	(V)	A)	(V)	Min(uA)	Max(uA)	(V)	Package
CT416B-800B	800	800	16	1.3	35000	50000	12	TO-220BK
CT416B-800C	800	800	16	1.3	10000	35000	12	TO-220BK
CT416B-600B	600	600	16	1.3	35000	50000	12	TO-220BK
CT416B-600C	600	600	16	1.3	10000	35000	12	TO-220BK
CT412B-800B	800	800	12	1.3	35000	50000	12	TO-220BK
CT412B-800C	800	800	12	1.3	10000	35000	12	TO-220BK
CT412B-800S	800	800	12	1.3	5000	10000	12	TO-220BK
CT412B-600B	600	600	12	1.3	35000	50000	12	TO-220BK
CT412B-600C	600	600	12	1.3	10000	35000	12	TO-220BK
CT412B-600S	600	600	12	1.3	5000	10000	12	TO-220BK
CT408R-800C	800	800	8	1.3	10000	35000	12	TO-262K
CT408R-800S	800	800	8	1.3	5000	10000	12	TO-262K
CT408R-600C	600	600	8	1.3	10000	35000	12	TO-262K
CT408R-600S	600	600	8	1.3	5000	10000	12	TO-262K
CT408D-800C	800	800	8	1.3	10000	35000	12	TO-252-2LK
CT408D-800S	800	800	8	1.3	5000	10000	12	TO-252-2LK
CT408D-600C	600	600	8	1.3	10000	35000	12	TO-252-2LK
CT408D-600S	600	600	8	1.3	5000	10000	12	TO-252-2LK
CT408B-800C	800	800	8	1.3	10000	35000	12	TO-220BK
CT408B-800S	800	800	8	1.3	5000	10000	12	TO-220BK
CT408B-600C	600	600	8	1.3	10000	35000	12	TO-220BK
CT408B-600S	600	600	8	1.3	5000	10000	12	TO-220BK
CT406D-800C	800	800	6	1.3	10000	35000	12	TO-252-2LK
CT406D-800S	800	800	6	1.3	5000	10000	12	TO-252-2LK
CT406D-600C	600	600	6	1.3	10000	35000	12	TO-252-2LK
CT406D-600S	600	600	6	1.3	5000	10000	12	TO-252-2LK
CT406B-800C	800	800	6	1.3	10000	35000	12	TO-220BK
CT406B-800S	800	800	6	1.3	5000	10000	12	TO-220BK
CT406B-600C	600	600	6	1.3	10000	35000	12	TO-220BK
CT406B-600S	600	600	6	1.3	5000	10000	12	TO-220BK
CT404E-800C	800	800	4	1.3	10000	35000	12	TO-126K
CT404E-800S	800	800	4	1.3	5000	10000	12	TO-126K
CT404E-600C	600	600	4	1.3	10000	35000	12	TO-126K
CT404E-600S	600	600	4	1.3	5000	10000	12	TO-126K
CT404D-800C	800	800	4	1.3	10000	35000	12	TO-252-2LK
CT404D-800S	800	800	4	1.3	5000	10000	12	TO-252-2LK
CT404D-600C	600	600	4	1.3	10000	35000	12	TO-252-2LK
CT404D-600S	600	600	4	1.3	5000	10000	12	TO-252-2LK
CT404B-800C	800	800	4	1.3	10000	35000	12	TO-220BK
CT404B-800S	800	800	4	1.3	5000	10000	12	TO-220BK
CT404B-600C	600	600	4	1.3	10000	35000	12	TO-220BK
CT404B-600S	600	600	4	1.3	5000	10000	12	TO-220BK
CT401T-800S	800	800	1	1.3	5000	10000	12	SOT-223-3LK
CT401T-800T	800	800	1	1.3		5000	12	SOT-223-3LK
CT401T-600S	600	600	1	1.3	5000	10000	12	SOT-223-3LK
CT401T-600T	600	600	1	1.3		5000	12	SOT-223-3LK
CT401L-800S	800	800	1	1.3	5000	10000	12	SOT-23-3LK
CT401L-800T	800	800	1	1.3		5000	12	SOT-23-3LK
CT401L-600S	600	600	1	1.3	5000	10000	12	SOT-23-3LK
CT401L-600T	600	600	1	1.3		5000	12	SOT-23-3LK
CT401J-800S	800	800	1	1.3	5000	10000	12	SOT-89K
CT401J-800T	800	800	1	1.3		5000	12	SOT-89K
CT401J-600S	600	600	1	1.3	5000	10000	12	SOT-89K
CT401J-600T	600	600	1	1.3		5000	12	SOT-89K
CT401G-800S	800	800	1	1.3	5000	10000	12	TO-92K
CT401G-800T	800	800	1	1.3		5000	12	TO-92K
CT401G-600S	600	600	1	1.3	5000	10000	12	TO-92K
CT401G-600T	600	600	1	1.3		5000	12	TO-92K
CT325B-800B	800	800	5	1.3	35000	50000	12	TO-220BK
CT325B-800C	800	800	25	1.3	10000	35000	12	TO-220BK
CT325B-800S	800	800	25	1.3	5000	10000	12	TO-220BK
CT325B-600B	600	600	25	1.3	35000	50000	12	TO-220BK
CT325B-600C	600	600	25	1.3	10000	35000	12	TO-220BK
CT325B-600S	600	600	25	1.3	5000	10000	12	TO-220BK
CT316R-800B	800	800	16	1.3	35000	50000	12	TO-262K
CT316R-800C	800	800	16	1.3	10000	35000	12	TO-262K
CT316R-800S	800	800	16	1.3	5000	10000	12	TO-262K
CT316R-600B	600	600	16	1.3	10000	35000	12	TO-262K
CT316R-600C	600	600	16	1.3	10000	35000	12	TO-262K
CT316R-600S	600	600	16	1.3	5000	10000	12	TO-262K
CT316B-800B	800	800	16	1.3	35000	50000	12	TO-220BK
CT316B-800C	800	800	16	1.3	10000	35000	12	TO-220BK
CT316B-800S	800	800	16	1.3	5000	10000	12	TO-220BK
CT316B-600B	600	600	16	1.3	35000	50000	12	TO-220BK
CT316B-600C	600	600	16	1.3	10000	35000	12	TO-220BK
CT316B-600S	600	600	16	1.3	5000	10000	12	TO-220BK
CT314Q-800B	800	800	14	1.3	35000	50000	12	TO-263K
CT314Q-800C	800	800	14	1.3	10000	35000	12	TO-263K
CT314Q-800S	800	800	14	1.3	5000	10000	12	TO-263K
CT314Q-600B	600	600	14	1.3	35000	50000	12	TO-263K
CT314Q-600C	600	600	14	1.3	10000	35000	12	TO-263K
CT314Q-600S	600	600	14	1.3	5000	10000	12	TO-263K
CT312Q-800B	800	800	12	1.3	35000	50000	12	TO-263K
CT312Q-800C	800	800	12	1.3	10000	35000	12	TO-263K
CT312Q-800S	800	800	12	1.3	5000	10000	12	TO-263K
CT312Q-600B	600	600	12	1.3	35000	50000	12	TO-263K
CT312Q-600C	600	600	12	1.3	10000	35000	12	TO-263K
CT312Q-600S	600	600	12	1..3	5000	10000	12	TO-263K
CT312B-800B	800	800	12	1.3	35000	50000	12	TO-220BK
CT312B-800C	800	800	12	1.3	10000	35000	12	TO-220BK
CT312B-800S	800	800	12	1.3	5000	10000	12	TO-220BK
CT312B-600B	600	600	12	1.3	35000	50000	12	TO-220BK
CT312B-600C	600	600	12	1.3	10000	35000	12	TO-220BK
CT312B-600S	600	600	12	1.3	5000	10000	12	TO-220BK
CT310D-800C	800	800	10	1.3	10000	35000	12	TO-252-2LK
MAC97A8	600	600	1	1.5		15000	12	TO-92
MAC97A6	400	400	1	1.5		15000	12	TO-92
BT136S	600	600	6	1.45		10000	12	TO-252-2L
BT136	600	600	6	1.45		10000	12	TO-220-3L
BT134	600	600	4	1.45		7000	12	TO-126
MCR100-8	600	600	0.8	0.8	5	200	7	TO-92
MCR100-6	400	400	0.8	0.8	5	200	7	TO-92
MCR100-8	600	600	0.8	0.8	5	200	7	SOT-89
MCR100-6	400	400	0.8	0.8	5	200	7	SOT-89
CT310D-800S	800	800	10	1.3	5000	10000	12	TO-252-2LK
CT310D-600C	600	600	10	1.3	10000	35000	12	TO-252-2LK
CT310D-600S	600	600	10	1.3	5000	10000	12	TO-252-2LK
CT308D-800C	800	800	8	1.3	10000	35000	12	TO-252-2LK
CT308D-800S	800	800	8	1.3	5000	10000	12	TO-252-2LK
CT308D-600C	600	600	8	1.3	10000	35000	12	TO-252-2LK
CT308D-600S	600	600	8	1.3	5000	10000	12	TO-252-2LK
CT308B-800C	800	800	8	1.3	10000	35000	12	TO-220BK
CT308B-800S	800	800	8	1.3	5000	10000	12	TO-220BK
CT308B-600C	600	600	8	1.3	10000	35000	12	TO-220BK
CT308B-600S	600	600	8	1.3	5000	10000	12	TO-220BK
CT306D-800C	800	800	6	1.3	10000	35000	12	TO-252-2LK
CT306D-800S	800	800	6	1.3	5000	10000	12	TO-252-2LK
CT306D-600C	600	600	6	1.3	10000	35000	12	TO-252-2LK
CT306D-600S	600	600	6	1.3	5000	10000	12	TO-252-2LK
CT304D-800S	800	800	4	1.3	5000	10000	12	TO-252-2LK
CT304D-800T	800	800	4	1.3		5000	12	TO-252-2LK
CT304D-600S	600	600	4	1.3	5000	10000	12	TO-252-2LK
CT304D-600T	600	600	4	1.3		5000	12	TO-252-2LK
CT304B-800S	800	800	4	1.3	5000	10000	12	TO-220BK
CT304B-800T	800	800	4	1.3		5000	12	TO-220BK
CT304B-600S	600	600	4	1.3	5000	10000	12	TO-220BK
CT304B-600T	600	600	4	1.3		5000	12	TO-220BK
BTA41-800BW	800	800	40	1.3	35000	50000	12	TO-3PK
BTA41-800CW	800	800	40	1.3	10000	35000	12	TO-3PK
BTA41-600BW	600	600	40	1.3	35000	50000	12	TO-3PK
BTA41-600CW	800	800	40	1.3	10000	35000	12	TO-3PK
BTA26-800BW	800	800	25	1.3	35000	50000	12	TO-3PK
BTA26-800CW	800	800	25	1.3	10000	35000	12	TO-3PK
BTA26-600BW	600	600	25	1.3	35000	50000	12	TO-3PK
BTA26-600CW	600	600	25	1.3	10000	35000	12	TO-3PK
BTA24-800BW	800	800	25	1.3	35000	50000	12	TO-220AK
BTA24-800CW	800	800	25	1.3	10000	35000	12	TO-220AK
BTA24-600BW	600	600	25	1.3	35000	50000	12	TO-220AK
BTA24-600CW	600	600	25	1.3	10000	35000	12	TO-220AK
BTA20-800BW	800	800	20	1.3	35000	50000	12	TO-220AK
BTA20-800CW	800	800	20	1.3	10000	35000	12	TO-220AK
BTA20-600BW	600	600	20	1.3	35000	50000	12	TO-220AK
BTA20-600CW	600	600	20	1.3	10000	35000	12	TO-220AK
BTA16-800BW	800	800	16	1.3	35000	50000	12	TO-220FK
BTA16-800CW	800	800	16	1.3	10000	35000	12	TO-220FK
BTA16-800SW	800	800	16	1.3	5000	10000	12	TO-220FK
BTA16-800BW	800	800	16	1.3	35000	50000	12	TO-220AK
BTA16-800CW	800	800	16	1.3	10000	35000	12	TO-220AK
BTA16-800SW	800	800	16	1.3	5000	10000	12	TO-220AK
BTA16-600BW	600	600	16	1.3	35000	50000	12	TO-220FK
BTA16-600CW	600	600	16	1.3	10000	35000	12	TO-220FK
BTA16-600SW	600	600	16	1.3	5000	10000	12	TO-220FK
BTA16-600BW	600	600	16	1.3	35000	50000	12	TO-220AK
BTA16-600CW	600	600	16	1.3	10000	35000	12	TO-220AK
BTA16-600SW	600	600	16	1.3	5000	10000	12	TO-220AK
BTA12-800CW	800	800	12	1.3	10000	35000	12	TO-220FK
BTA12-800SW	800	800	12	1.3	5000	10000	12	TO-220FK
BTA12-800TW	800	800	12	1.3		5000	12	TO-220FK
BTA12-800CW	800	800	12	1.3	10000	35000	12	TO-220AK
BTA12-800SW	800	800	12	1.3	5000	10000	12	TO-220AK
BTA12-800TW	800	800	12	1.3		5000	12	TO-220AK
BTA12-600CW	600	600	12	1.3	10000	35000	12	TO-220FK
BTA12-600SW	600	600	12	1.3	5000	10000	12	TO-220FK
BTA12-600TW	600	600	12	1.3		5000	12	TO-220FK
BTA12-600CW	600	600	12	1.3	10000	35000	12	TO-220AK
BTA12-600SW	600	600	12	1.3	5000	10000	12	TO-220AK
BTA12-600TW	600	600	12	1.3		5000	12	TO-220AK
BTA08-800CW	800	800	8	1.3	10000	35000	12	TO-220FK
BTA08-800SW	800	800	8	1.3	5000	10000	12	TO-220FK
BTA08-800TW	800	800	8	1.3		5000	12	TO-220FK
BTA08-800CW	800	800	8	1.3	10000	35000	12	TO-220AK
BTA08-800SW	800	800	8	1.3	5000	10000	12	TO-220AK
BTA08-800TW	800	800	8	1.3		5000	12	TO-220AK
BTA08-600CW	600	600	8	1.3	10000	35000	12	TO-220FK
BTA08-600SW	600	600	8	1.3	5000	10000	12	TO-220FK
BTA08-600TW	600	600	8	1.3		5000	12	TO-220FK
BTA08-600CW	600	600	8	1.3	10000	35000	12	TO-220AK
BTA08-600SW	600	600	8	1.3	5000	10000	12	TO-220AK
BTA08-600TW	600	600	8	1.3		5000	12	TO-220AK
BTA06-800CW	800	800	6	1.3	10000	35000	12	TO-220FK
BTA06-800SW	800	800	6	1.3	5000	10000	12	TO-220FK
BTA06-800TW	800	800	6	1.3		5000	12	TO-220FK
BTA06-800CW	800	800	6	1.3	10000	35000	12	TO-220AK
BTA06-800SW	800	800	6	1.3	5000	10000	12	TO-220AK
BTA06-800TW	800	800	6	1.3		5000	12	TO-220AK
BTA06-600CW	600	600	6	1.3	10000	35000	12	TO-220FK
BTA06-600SW	600	600	6	1.3	5000	10000	12	TO-220FK
BTA06-600TW	600	600	6	1.3		5000	12	TO-220FK
BTA06-600CW	600	600	6	1.3	10000	35000	12	TO-220AK
BTA06-600SW	600	600	6	1.3	5000	10000	12	TO-220AK
BTA06-600TW	600	600	6	1.3		5000	12	TO-220AK
BTA04-800CW	800	800	4	1.3	10000	35000	12	TO-220FK
BTA04-800SW	800	800	4	1.3	5000	10000	12	TO-220FK
BTA04-800TW	800	800	4	1.3		5000	12	TO-220FK
BTA04-800CW	800	800	4	1.3	10000	35000	12	TO-220AK
BTA04-800SW	800	800	4	1.3		5000	12	TO-220AK
BTA04-800TW	800	800	4	1.3		5000	12	TO-220AK
BTA04-600CW	600	600	4	1.3	10000	35000	12	TO-220FK
BTA04-600SW	600	600	4	1.3	5000	10000	12	TO-220FK
BTA04-600TW	600	600	4	1.3		5000	12	TO-220FK
BTA04-600CW	600	600	4	1.3	10000	35000	12	TO-220AK
BTA04-600SW	600	600	4	1.3	5000	10000	12	TO-220AK
BTA04-600TW	600	600	4	1.3		5000	12	TO-220AK
CR825B	800	800	25	1	2000	25000	12	TO-220BK
CR816B	800	800	16	1	2000	25000	12	TO-220BK
CR812D	800	800	12	1	2000	25000	12	TO-252-2LK
CR812B	800	800	12	1	2000	25000	12	TO-220BK
CR620B	600	600	20	1	2000	25000	12	TO-220BK
CR612B	600	600	12	1	2000	25000	12	TO-220BK
CS040E	600	600	4	0.8	10	200	12	TO-126K
CS030E	600	600	3	0.8	12	200	12	TO-126K
CS012T	600	600	1.2	0.8	10	200	12	SOT-223-3LK
CS008L	600	600	0.8	0.8	10	200	12	SOT-23-3LK
CS008G	600	600	0.8	0.8	10	200	12	TO-92K
MCRN100-6	400	400	0.8	0.8	5	200	7	SOT-89
PCR0.6	400		0.6	0.8	5	40	7	SOT-23
PCR0.6	400		0.6	0.8	5	120	7	TO-92
